Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409

Name: Incoloy 800 800H Nickel Alloy Plate UNS N08800 UNS N08810 Plate Sheet ASME B409
Brand: DELTA
Price: 40 USD

Quality Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409 wholesale

Brand Name : DELTA

Model Number : 8810 Alloy / UNS N08810

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 40-45 USD/Kg

Payment Terms : L/C, T/T, Western Union

Supply Ability : 3 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Nickel alloy bars

Grade : 8810 Alloy / UNS N08810

Thickness : 0.6 - 20.0mm

Size : 1219*2438 1500*6000mm

Standard : ASTM EN

Service : Cutting

Loading Port : Shanghai Port

Surface : 2B NO.1

Contact Now

Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409

Products Description

Product Name	Incoloy 800/800H/800HT Plate/Sheet (UNS N08800,UNSN 08810,UNSN 08811)
Technology	Hot rolled , Cold rolled
Grade	Inconel 600, Inconel 601, Inconel 625, Inconel 617, Inconel 690, Inconel 718, Inconel X-750
	Incoloy A-286, Incoloy 800, Incoloy 800H, Incoloy 800HT Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926
	Monel 400, Monel K-500
	Hastelloy C22, Hastelloy C-276, Hastelloy B-2, Hastelloy B-3, Hastelloy X
Specifications	ASTM, UNS, JIS, EN, AFNOR
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Processing Service	Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining Deformation processing : Bending / Cutting / Rolling / Stamping
Delivery time	10-30 days subject to the clients' requirement and quantity
Package	clients' requirement and Standard export sea-worthy packing
MOQ	1 ton

Incoloy 800/800H/HT Plate/Sheet

Alloy 800 series (Incoloy 800, 800H and 800HT) are nickel-iron-chromium superalloys that offer high temperature strength and resistance to oxidation, carburization and other types of high-temperature corrosion.

Available Size Range

Dimension	Range
thickness	0.2-100mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, etc. or customer's request
Length	1000mm~6000mm, or as customer's request

Chemical Analysis

	%	C	Mn	Si	Gr	S	Ni	Cu	Fe	Ai	Ti
800	Min.	-	-	-	19	-	30	-	Balance	0. 15	0. 15
800	Max.	0.10	1.5	1	23	0. 015	35	0.75	Balance	0.60	0.60
800H	Min.	0. 05	-	-	19	-	30	-	Balance	0. 15	0. 15
800H	Max.	0.10	1.5	1	23	0. 015	35	0.75	Balance	0.60	0. 6
800HT	Min.	0. 06	-	-	19	-	30	-	Balance	0. 15	0. 15
800HT	Max.	0.10	1.5	1	23	0. 015	35	0.75	Balance	0.60	0.60

Mechanical Properties

Mechanical properties	Tensile, min, ksi[MPa]	Yield, min, ksi[MPa]	Elongation, %(min)
Incoloy 800	75[517]	30[207]	30
Incoloy 800H	65[448]	25[172]	30
Incoloy 800HT	65[448]	25[172]	30
Incoloy 825	85[586]	35[241]	30

Applications

800 Heat exchangers and process piping Furnace components Ammonia effluent coolers

800H Chemical and petrochemical processing Pressure vessels Heat exchangers Industrial furnaces
